BELL HTL-4
|
|
| Manufacturer: | Bell |
| Designation: | HTL |
| Version: | -4 |
| Nickname: | Sioux |
| Equivalent to: | TH-13L |
| Designation System: | U.S. Navy / Marines |
| Designation Period: | 1948-1962 |
| Basic role: | Training |
Specifications
| Length: | 27' 4" |
| Height: | 9' 2" |
| Wing span: | 35' 1" |
| Wing area: | 965.0 sq. ft. |
| Empty Weight: | 1,380 lb. |
| Gross Weight: | 2,078 lb. |
| Max Weight: | 2,350 lb. |
Propulsion
| No. of Engines: | 1 | ||
| Power plant: | Franklin O-335-5B | ||
| Horsepower: | 200 | ||
Performance
| Range: | 250 miles |
| Cruise Speed: | 92 mph |
| Max Speed: | 100 mph |
| Ceiling: | 10,900 ft. |
